hechuang linkpro ad hoc network emergency communication command system

linkpro broadband wireless self-organizing emergency communication command system is a communication equipment launched by guangdong hechuang electronic technology co., ltd. for forest, high-rise buildings, dense buildings, underground shopping malls, underground garages, subway tunnels and urban tunnels. the equipment can be carried by a single soldier or combined with the original pdt system, and can flexibly undertake the information collection and management of a single soldier wireless link relay, on-site video return and other tasks to achieve seamless coverage of the designated area, quickly open the communication link from the fire and disaster relief site to the headquarters, ensure efficient command and coordination of disaster relief work, and maximize the personal safety of disaster relief personnel.

hotline：

400-168-6661

product introduction

product function

when the forest, high-rise buildings, dense buildings, underground shopping malls, underground garages, subway tunnels and urban tunnels and other scenes occur after accidents such as fire and earthquake, it is difficult for traditional communication means to form effective coverage to ensure reliable on-site command, coordination and dispatching, so that the disaster relief work can not be implemented efficiently, and the safety of fire and disaster relief personnel can not be reliably guaranteed. linkpro broadband wireless self-organizing emergency communication command system can realize seamless coverage of the designated area, quickly open the communication link from the fire and disaster relief site to the headquarters, ensure the rapid and smooth completion of disaster relief tasks, and ensure the safety of disaster relief personnel.

product parameter

linkpro broadband wireless ad hoc emergency communication command system consists of lh individual mesh radio, integrated mesh radio and mesh communication command box.

lh单兵mesh电台产品参数：

无线通讯性能
通讯体制	cofdm
频段	支持l band/u band/s band
带宽	2.5/5/10mhz
灵敏度	-103dbm
射频功率	24 dbm *2
最高吞吐量	27mbps @10mhz
组网性能	32个节点
wifi	内置
gps	选配
天线	cofdm2 wifi1
i/o
eth	1
usb	1
com	1
audio	1
物理参数
主机尺寸	145mm x 80mm x 38mm ，540g
带电池尺寸	230mm x 80mm x 38mm ，900g
电源	dc11.1～12.6v
整体功耗	≤8w
工作温度	-20度～65度

一体化mesh电台参数：

无线通讯性能
通讯体制	cofdm
频段	支持l band/u band/s band
带宽	2.5/5/10mhz
灵敏度	-103dbm
射频功率	33 dbm *2
最高吞吐量	27mbps @10mhz
组网性能	32个节点
wifi	内置
gps	选配
天线	cofdm2 wifi1
i/o
eth	1
usb	1
com	1
tb	1
物理参数
主机尺寸	194mm x 176mm x 60mm ，3500g
电源	dc～26-36v
整体功耗	24w
工作温度	-20度～65度

mesh通讯指挥箱参数：

无线通讯性能
通讯体制	cofdm
频段	支持l band/u band/s band
带宽	2.5/5/10mhz
灵敏度	-103dbm
射频功率	33 dbm *2
最高吞吐量	27mbps @10mhz
组网性能	32个节点
wifi	内置
gps	选配
天线	cofdm2 wifi1
i/o
eth	1
usb
com	1
tb	1
hdmi	1
物理参数
主机尺寸	418mm x 330mm x 173mm
电源	dc26～36v
整体功耗	≤28w
工作温度	-20度～65度
