hechuang hc100100dx ray safety inspection equipment

hechuang hc100100d (dual source and dual viewing angle) x-ray safety inspection equipment is a multi-energy x-ray inspection equipment independently developed by guangdong hechuang electronic technology co., ltd. it adopts two groups of independent x-ray light source inspection systems to simultaneously collect image data from horizontal and vertical directions at high speed. even if the tested object is placed at any angle, it can output the object contour in three dimensions, effectively identify the object shape and solve the problem of missed detection and false alarm caused by occlusion.

hotline:

400-168-6661

product introduction

hechuang hc100100d (dual source and dual viewing angle) x-ray safety inspection equipment is a multi-energy x-ray inspection equipment independently developed by guangdong hechuang electronic technology co., ltd. it adopts two groups of independent x-ray light source inspection systems to simultaneously collect image data from horizontal and vertical directions at high speed. even if the tested object is placed at any angle, it can output the object contour in three dimensions, effectively identify the object shape and solve the problem of missed detection and false alarm caused by occlusion.




leading edge

comprehensive leading: the product performance parameters have reached the international first-class level, high-definition image, strong penetration, high resolution and strong material identification function


high end components: high-end high-quality brands such as sens tech acquisition system imported from britain, hamamatsu original detector from japan and digital ray source are adopted, with stable quality and performance, which is the highest configuration in china


real parameters: the performance parameters of the product in actual use are completely consistent with the test report issued by the ministry of public security, and the test report results are more authentic and reliable


stable and reliable: the product production process is controlled in strict accordance with iso9001 quality management system. through strict high and low temperature test, damp heat test and vibration test, the product can operate continuously without fault for more than 10000 hours


stable frame: it adopts national standard 304 stainless steel, 2-3mm national standard cold rolled plate and fangtong steel, integrates advanced technology, has stable and firm structure, rust prevention, corrosion prevention and cable damage


service guarantee: 24-hour after-sales telephone to provide customers with technical support at any time. the 150 person service team is distributed in all provinces of the country to provide installation, maintenance and overhaul services detection effect diagram






technical index

basic parameters

channel size 1000mm (width) * 1000mm (height)


conveyor belt speed 0.22m/s


maximum load capacity 200kg


penetration top illumination angle: greater than 40mm steel plate side illumination angle: greater than 40mm steel plate


line resolution top illumination angle: φ 0.0787mm wire side illumination angle: φ 0.0787mm wire


penetration resolution top illumination angle: φ 0.202mm wire side illumination angle: φ 0.160mm wire


spatial resolution overhead viewing angle: horizontal: φ 1.0mm, vertical: φ 1.0mm side view angle: horizontal: φ 1.0mm, vertical: φ 1.0mm


radiation safety


the single examination dose is less than 3.1 μ gy


the leakage ray dose rate is less than 0.2 μ gy / h (tested at any place 5cm away from the external surface of the equipment, it meets and is superior to the health and safety standards at home and abroad)


high efficiency radiation protection adopts double-layer staggered, wear-resistant and solid lead curtain, and ultra thick 2-5mm lead plate to ensure the safety and reliability of the equipment


x-ray generator


digital interface tube voltage 80-160kv (adjustable), current 0.3-1.2ma (adjustable)


cooling / duty cycle sealed oil cooling / 100%


equipment function

image processing functions: color / black and white, local increase, high wear, low wear, super increase, organic removal, inorganic removal, anti color, brightening, dimming, gray scanning, amplification, false color, organic enhancement, suspicious object alarm mark, edge enhancement processing


system functions: power on self-test, multi-level user management, image management, tip management, curve diagnosis, keyboard diagnosis, equipment information query, multi format image export, osd operation function, image mirroring, 1-64 times stepless magnification, magnifying glass, operator training, accurate positioning of package images, channel emptying reminder, remote operation software, one click shutdown intelligent roller (optional)


structural design


the unique anti - pinch design, safe and reliable, is under the belt at the inlet and outlet of the anti - pinch device channel and the receiving frame


three dimensional indicator light, four corner column indicator light, full angle and timely display the working state of the equipment, with simple and beautiful appearance


humanized design professional keyboard, with ergonomic workbench, easy to use and comfortable


high quality belt conveyor belt surface diamond grain printing, more resistant to cutting and scraping in use; 3mm thickness is more tensile resistant and not easy to deform; the surface is anti - static, so it is not easy to be polluted



installation data


overall dimension (excluding receiving rack) 3916mm (l) * 1781mm (w) * 1885.5mm (h)


working power supply 220vac (± 10%) 50 ± 3hz


power consumption: 1.5kw
