hc1009 portable metal detection door-尊龙登录

portable security door is a portable and high-performance security door. the metal detection sensitivity of this security door is high. it is portable, movable, waterproof and lightweight. it can be deployed and transported to any place with only one operator and assembled in five minutes to make it work normally. it is ideal for sports meetings, meetings metal detection doors for schools and other occasions. at the same time, it also has the characteristics of simple operation and complete portability, so it is easy to operate and can be used without any operation training.

the product has obtained a number of appearance agency patents and has obtained the registered 尊龙凯时官网登录 copyright of the software system. this product is a detection structure that uses electromagnetic field to detect portable metal objects, and indicates that the amount of portable metal objects exceeds a certain amount by means of audible and visual alarm. it is composed of host, high frequency signal generator, signal receiver and infrared sensor. it has the characteristics of beautiful appearance, strong metal detection ability, many detection and defense areas, unique internet remote operation management system, portability and waterproof. it can be disassembled into 8 components and can be easily carried and transported. it is a leading portable security door in the market.

1. multi zone technology: 8, 16 and 24 detection zones can provide self switching and intelligent zoning (more zone upgrade technologies can be provided).


2. working frequency band: super large range working frequency band (0-120), with adaptive function of working environment.


3. detection zone sensitivity: the sensitivity of a single zone can be adjusted up to 355 levels.


4. mobile internet technology: realize remote control of mobile app and zero distance in the world.


5. super strong shell protection technology: ip67 superior protection performance (optional).


6. adaptive diagnosis system: the system detects the working state of the hardware during startup to escort you.

1. adaptive debugging system: when the system enters the debugging system, it can adaptively debug the detection standard.


2. start stop technology: the infrared device has automatic start stop technology, and the service life is extended by 100 times.


3. the sensitivity of each detection zone can be adjusted arbitrarily (with adaptive adjustment technology).


4. the division of detection and defense zones can be adjusted by themselves (the number of detection and defense zones can be prepared by themselves).


5. sound and light alarm, alarm tone and alarm duration can be adjusted arbitrarily.


6. query function: the system has real-time information query function.


7. detection ability: it has the detection passing ability of more than 100 people in 1 minute.

test object: prohibited articles, more magnetic metals;


channel size: 2051x710x500mm (width can be customized 700 ~ 1500mm);


folding size: 889x606x484mm;


vertical overall dimension: 2250x850x500mm


package size: 948x666x525mm;


working humidity: 99%, non condensing;


working environment: - 40 ℃ ~ 85 ℃;


power supply mode: the whole system is equipped with polymer batteries, with optional service life of 8, 16, 24, 48 and 72 hours;


input: ac 110v ~ 240v / 50hz ~ 60hz


output: dc 12v / 5a 12w


weight: net weight 42kg, gross weight 50kg;

1. high and low temperature resistance: 600t s can work normally at - 40 ℃ to 85 ℃ (optional)


2. waterproof and rainproof: the new deep-sea waterproof technology can work normally even in 0.72m water


3. wireless connection: master the security door anytime and anywhere. the products are wirelessly connected to the internet through wifi, 4g data and bluetooth modules. remote control, data monitoring and world zero distance are realized through mobile app and computer client (optional)


4. ultra long power supply time: the whole system is equipped with polymer batteries, with optional service life of 4, 8, 16, 24, 48 and 72 hours. the system has low battery alarm function, standard configuration (4 hours)
