hechuang hc6550d dual source dual view x-ray safety inspection equipment

hechuang hc6550d (dual source and dual viewing angle) x-ray safety inspection equipment is a multi-energy x-ray inspection equipment independently developed by guangdong hechuang electronic technology co., ltd. it adopts two groups of independent x-ray light source inspection systems to simultaneously collect image data from horizontal and vertical directions at high speed. even if the tested object is placed at any angle, it can output the object contour in three dimensions, effectively identify the object shape and solve the problem of missed detection and false alarm caused by occlusion.

hotline:

400-168-6661

product introduction

hechuang hc6550d (dual source and dual viewing angle) x-ray safety inspection equipment is a multi-energy x-ray inspection equipment independently developed by guangdong hechuang electronic technology co., ltd. it adopts two groups of independent x-ray light source inspection systems to simultaneously collect image data from horizontal and vertical directions at high speed. even if the tested object is placed at any angle, it can output the object contour in three dimensions, effectively identify the object shape and solve the problem of missed detection and false alarm caused by occlusion.



basic parameters:

channel size 650mm (width) * 500mm (height)


conveyor belt speed 0.22m/s


maximum load capacity 170kg


penetration bottom illumination angle: more than 40mm steel plate side illumination angle: more than 40mm steel plate


line resolution bottom illumination angle: φ 0.0787mm wire side illumination angle: φ 0.0787mm wire


penetration resolution bottom illumination angle: φ 0.202mm wire side illumination angle: φ 0.160mm wire


spatial resolution bottom illumination angle of view: horizontal: φ 1.0mm, vertical: φ 1.0mm side view angle: horizontal: φ 1.0mm, vertical: φ 1.0mm


radiation safety


the single examination dose is less than 3.1 μ gy


the leakage ray dose rate is less than 0.2 μ gy / h (tested at any place 5cm away from the external surface of the equipment, it meets and is superior to the health and safety standards at home and abroad)


high efficiency radiation protection adopts double-layer staggered, wear-resistant and solid lead curtain, and ultra thick 2-5mm lead plate to ensure the safety and reliability of the equipment


x-ray generator

digital interface tube voltage 80-160kv (adjustable), current 0.3-1.2ma (adjustable)


cooling / duty cycle sealed oil cooling / 100%


equipment function


image processing functions: color / black and white, local increase, high wear, low wear, super increase, organic removal, inorganic removal, anti color, brightening, dimming, gray scanning, amplification, false color, organic enhancement, suspicious object alarm mark, edge enhancement processing


system functions: power on self-test, multi-level user management, image management, tip management, curve diagnosis, keyboard diagnosis, equipment information query, multi format image export, osd operation function, image mirroring, 1-64 times stepless magnification, magnifying glass, operator training, accurate positioning of package images, channel emptying reminder, remote operation software, one click shutdown intelligent roller (optional)
