hc100100 channel x-尊龙登录

specially designed for stations, docks, airports and other important places


strict internal quality control and implementation of the principle of double inspection of engineering and production


guarantee measures for complete machine parts


*passed iso9001 certification


*passed iso14001 environmental certification


*osha28001 occupational health management system certification


*radiation safety certification


*passed the cdc radiation test


*it has passed the inspection of the safety and police electronic product quality inspection center of the ministry of public security

channel size 1000 (width) × 1000 (height) mm


belt speed 0.2 m / s


uniform load of conveyor belt 200 kg


single inspection dose < 1.5 µ gy


*resolution diameter 0.0101mm metal wire


*the penetration force can penetrate 34mm steel plate


*display 19 inch hd lcd


film safety to iso1600 film safety


leakage dose < 0.2 µ gy / h

ray beam direction bottom illumination type


tube current 0.4 ~ 1.2ma (adjustable)


tube voltage 100 ~ 160 kv (adjustable)


beam divergence angle 60 °


cooling / duty cycle sealed oil cooling / 100%

operating temperature / humidity: 0 ℃ ~ 45 ℃ / 20% ~ 95% (non condensing)


storage temperature / humidity - 20 ℃ ~ 60 ℃ / 20% ~ 95% (non condensing)


working voltage 220vac (± 10%) 50 ± 3hz


power loss 1.2kw (max.)


*noise level ≤ 58db

*auxiliary explosive detection procedure


*the storage capacity of pictures is more than 300000 and can be called for printing at will


*environmentally friendly lead curtain to avoid lead pollution


*external usb flash disk interface, look at the pictures


*ray source automatic adjustment program


*operator identification procedure
