strict internal quality control and implementation of the principle of double inspection of engineering and production


guarantee measures for complete machine parts


*passed the national standard gb15208 1-2005 test


*passed iso9001 certification


*passed iso14001 environmental certification


*osha18001 occupational health management system certification


*radiation safety certification


*passed the radiation dose test of provincial vocational prevention hospital


*through software enterprise certification and software product certification


*it has passed the inspection of the safety and police electronic product quality inspection center of the ministry of public security

channel size 500 (width) × 300 (height) mm


conveyor belt speed 0.2 ± 0.02m/s


the conveyor belt has a uniform load of 200 kg


the maximum load of a single package on the conveyor belt is 20kg


single inspection dose < 1.2 µ gy


*resolution diameter 0.0787mm metal wire


*steel plate with penetration ＞ 42mm


film safety to iso1600 film safety


leakage dose < 0.12 µ gy / h (national standard is no more than 5 µ gy / h)


☆ x-ray generator


ray beam direction bottom illumination type


tube current 0.4 ~ 1.2ma (adjustable)


tube voltage 100 ~ 160 kv (adjustable)


beam divergence angle 80 °


cooling / duty cycle sealed oil cooling / 100%


☆ image processing system:


x-ray sensor l-shaped photodiode detector (imported from japan)


display 19 inch hd lcd


image display 24 bit true color, image enhancement, edge enhancement, high energy high wear, high energy low wear


smooth image enlargement, image brightening and darkening, arbitrary image pullback, and automatic image storage


the multi energy penetrating organic matter is displayed in orange, the inorganic matter is displayed in blue, and the mixture is displayed in green

operating temperature / humidity - 10 ℃ ~ 45 ℃ / 10% ~ 95% (non condensing)


storage temperature / humidity - 20 ℃ ~ 60 ℃ / 10% ~ 95% (non condensing)


working voltage 220vac (± 10%) 50 ± 3hz


power loss 0.7kw (max.)


*noise level ≤ 58db

*the storage capacity of pictures is more than 500000, and printing can be called at will


*dangerous goods prompt function


*luggage counting function


*one touch shutdown function


*dynamic picture switching function


*environmentally friendly lead curtain to avoid lead pollution


*external usb flash disk interface, look at the pictures


*ray source automatic adjustment program


*operator identification procedure
