hc-rtsm-02 millimeter wave human security detector

hc-rtsm-02毫米波人体安检仪是一款无电离辐射的人体安检仪,设备可对人体衣物内,藏匿的金属、液体、塑料等材质的潜在危险品进行自动识别、三维成像和自动报警,毫米波的波长,刚好可以穿透衣物,获取人体表面信息,也很好的保护了被检测人员的隐私,是一款新型的安检设备。

hotline:

400-168-6661

product introduction

hc-rtsm-02 millimeter wave human body security detector is a human body security detector without ionizing radiation. the equipment can automatically identify, three-dimensional image and automatically alarm potential dangerous goods of metal, liquid, plastic and other materials hidden in human clothes. the millimeter wave wavelength can just penetrate clothes to obtain human body surface information and protect the privacy of the tested personnel, it is a new type of security inspection equipment.




技术指标

工作电源

ac220v/50hz

峰值功率

600w

工作环境温度

-5~55

工作环境湿度

15%~95%

储存环境温度

-20~70

储存环境湿度

15%~95%

设备尺寸

1830(长)x880(宽)x2250mm(高)

设备重量

300kg



product advantages:

1.360 ° scanning, the first in the world and the only in the industry.


high performance 3d array scanning technology is used to achieve 360 degree omnidirectional scanning of human body surface, which effectively covers the whole body and has no angle blind area. using multi angle imaging technology, the collected human body image data is richer and of higher quality;



2. automatic and efficient


the system automatically and quickly discriminates and alarms without manual intervention.


3. intelligent and accurate


the industry-leading artificial intelligence algorithm, based on tens of millions of data, uses deep learning technology and accurate algorithm iteration model to continuously improve the accuracy.


4. green safety:


the equipment has the advantages of small power, low power consumption, green, safe and environmental protection, and does not produce ionization harmful to human body.


5. privacy protection:


non contact scanning, face blur processing, support human image switching


6. small volume, light weight and less restricted by the site environment.


specification and size: 1835mm (l) x8880mm (w) x2250mm (h);


weight: 221.5kg;


7. easy to use:


support mobile terminal operation


8. strong scalability:


support multi network online, unified management, and can be customized according to customer requirements


9. fully open structural design, the inspection process is clear at a glance
